| Item | Contents | Specification |
|---|---|---|
| IPC | System | X-Worker Flexible Control System |
| Compatible Controller | brother, FANUC, SIEMENS, MITSUBISHI, HEIDENHAIN, SYNTEC, GSK and HNC etc. | |
| Robot | Type | XTEC specified Robot (FANUC Robot as an option) |
| Maximum Loading | 10Kg | |
| Reach | Approx. 1468mm | |
| Repeatability | ±0.05mm | |
| Gripper | Single or Combined | |
| Parameter | Capacity | 78*1 |
Max. weight of workpiece | 8kg*2 | |
| Max. height of workpiece | 150mm | |
Rack | Single-Rack (Standard) | Beam Type |
Dual-Rack (Option) | Beam Type | |
Size | Dimension(L*W*H) | Approx. 1500mmΧ1156mmX2000mm*2 |
| Safety*3 | Metal cover | Metal cover |
| Safety fence | Optional | |
| Radar Sensor | Optional |
| Voltage | 220V AC +10% to -10% ,3-Phase or 220V AC, 1-Phase 50/60±1Hz |
| Power | 6.5kVA |
| Air Pressure | ≥0.6MPA |
| Net Weight | Approx. 750kg |
*1 Capacity of rack change in case of workpiece size change.
*2 Maximum weight of the workpiece may change when use different
gripper.
*3 Capacity of rack change in case of workpiece maximum height change.
